    Solar Inverter Energy Meter ACR10R16DTE4 Three Phase Energy Meter

    General


    sollis inverter energy meter ACR10R16DTE4 three phase energy meter is suitable for energy-saving renovation projects in high energy consumption industries such as smelting, steel, electric welding, semiconductor, etc. It is also suitable for power monitoring of distributed photovoltaic grid-connected cabinets, power demand side management and other applications .


    Technical parameter


    Technical parameterssollis inverter energy meter ACR10R16DTE4 three phase energy meter
    InputGridSingle-phase
    Frequency45~65Hz
    VoltageRated voltage: AC 100V, 400V
    Overload: 1.2 times the rated voltage(continuous); 2 times the rated voltage lasting for 1 second
    Power consumption: less then 0.2VA
    CurrentRated current: 10A,20A,40A,80A,120A,200A etc. (for details see product specifications)
    Overload: 1.2 times the rated current(continuous);10 times the rated current lasting for 1 second
    Power consumption: less then 0.2VA
    OutputCommunicationRS485 interface, Modbus-RTU
    DisplayLCD
    Measurement precisionVoltage: 0.2 level, current, power Active energy: 0.5 level,0.01Hz frequency, Reactive energy: 1 level
    Power supplyAC85~265V or DC100~350V; power consumption ≤10VA
    SafetyPower frequency withstand voltage

    AC2kV 1 min between power supply // current input//voltage input and communication

    AC2kV 1 min between each pair of combinations among power supply, urrent input and voltage input.

    Insulating resistorInput,output terminal to housing >100MΩ
    Environment

    Working temperature: -10℃~+55℃;storage temperature: -20℃~+70℃

    Relative humidity:5%~95%,non-condensing; altitude:≤2500m

    Features


    sollis inverter energy meter ACR10R16DTE4 three phase energy meter

    Used for distributed&centralized Solar PV

    ● Rogowski Coil for Centralized Solar PV

    ● Split-core CTs for Distributed Solar PV

    ● Reflux Monitoring

    ● Harmonic Monitoring

    Application scenario of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter

    Bidirectional Power Metering

    ● Active Power Metering

    ● Reactive Power Metering

    Bidirectional power metering of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter

    RS485 Communication

    ● MODBUS-RTU Protocol

    ● Communicate with Inverter to realize anti-reflux Function

    RS485 of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter to be communicate with inverter for Anti-reflux function

    Keypads HMI for Programming

    ● Parameter Display Setting

    ● Communication(address, baud rate and etc.)

    ● Wiring: 3P3W,3P4W

    Keypads HMI of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter

    Wiring


    3-phase 4-wire wiring of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter with external CTs

    Application


    Application of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter in Solar PV power monitoring system

    Practical utility of ACR10R-DxxTEx Three-phase PV Reflux Monitoring Meter in distributed Solar PV
